The Science Behind Resin Bond Grinding Wheels: How They Work and Where They Excel

In the world of machining and precision grinding, engineers and manufacturers are constantly seeking ways to enhance efficiency and finish parts to increasingly tighter tolerances. A key player in this arena is the Resin Bond superabrasive grinding wheel. This remarkable technology has revolutionized the way hard materials are shaped and finished. In this article, we will look at the science behind Resin Bond grinding wheels, understanding how they work and why they excel in various applications.

Understanding the Basics

Before we dive into the intricacies of Resin Bond grinding wheels, it is essential to understand the core fundamentals that govern their operation.

1. Resin Bond: Resin is a polymeric (plastic) material that can be formed under specific conditions. At Continental Diamond Tool, our Resin Bond products are created using phenolic and polyimide resins, which are combined with conventional abrasives, superabrasives, and metal powders to form specific grinding structures. The thermosetting resins are the bonding agent that hold the abrasive materials (typically Diamond or CBN) in place. Once blended together, wheel compositions are “hot pressed” to specific sizes & shapes in special molds, and the resins are cured.  After hot pressing to near-net shape, they are machined to final dimensions and tolerances for customer use. Resin Bonds are highly regarded for their ability to provide a firm mechanical grip on abrasive particles, ensuring stability during the grinding process. It is this bonding, combined with flexibility of grinding structures, that allow for the customization required for efficient grinding of a variety of materials and applications.

2. Abrasive Material: Abrasive materials are used in grinding, cutting, and shaping processes to remove material from workpieces. They differ in terms of hardness, durability, and efficiency. Superabrasive materials are a special class of abrasive known for exceptionally high hardness, wear resistance, and cutting efficiency. The two superabrasive materials we use at Continental Diamond Tool are Diamond and Cubic Boron Nitride (CBN). Diamonds are ideal for grinding and cutting extremely hard materials like ceramics, glass, and precious stones, while CBN is used for grinding ferrous materials like steel and hardened alloys. When superabrasives are embedded in a resin matrix, it creates an incredibly effective cutting and grinding tool when compared with conventional abrasives like Aluminum Oxide and Silicon Carbide grinding wheels.

3. Wheel Structure: The arrangement of abrasive material and fillers within the resin matrix forms the wheel's abrasive surface. These abrasives can be designed in various shapes and concentrations, depending on the intended application. Variables like abrasive grain type, size, shape, concentration, bond type, porosity, wheel grade, and design are carefully engineered to determine the wheel's performance characteristics: its cutting ability, surface finish quality, heat dissipation, suitability for specific grinding applications, and more.

How It Works

Resin Bond superabrasive wheels are employed in a wide range of applications, from grinding high hardness materials to sharpening other Diamond or CBN cutting tools. For optimal efficiency, Resin Bond grinding wheels perform best with applications that are well-suited to the way these wheels interact with the workpiece.

1. Cutting Action: When a Resin Bond wheel is brought into contact with a workpiece, the Diamond or CBN abrasives on the wheel's surface come into play. Superabrasives are exceptionally hard, making them capable of cutting through even the toughest materials.

2. Heat Generation: As the wheel cuts through the workpiece, friction generates heat. Both Diamond and CBN are excellent thermal conductors, but Resin Bonds do not inherently conduct heat well. As a plastic, Resin Bond deteriorates at pretty low temperatures compared with other bonds. Its wheel performance is best when coolants and compositions are tailored for “dry grinding” applications. In applications where heat dissipation is a priority, Resin Bond formulations can be manipulated by adding conductive metals such as copper or aluminum to remove heat more efficiently.

3. Wear and Tear: Grinding forces erode equipment over time. Unlike traditional abrasive wheels that wear down quickly and require frequent dressing to stay effective, Resin Bond superabrasive wheels can be formulated to be self-dressing. As the abrasive diamonds wear, new grains are exposed, maintaining a consistent cutting edge throughout the wheel's life.

4. Edge Stability: Edge stability refers to a tool’s ability to maintain the sharpness and integrity of its cutting edge over time. The combination of the high hardness superabrasive with the strong mechanical bond of the resin binder provides excellent edge stability and sharpness, which makes for more efficient grinding. Good edge retention increases productivity and reduces cycle times through less frequent tool changes and consistent cutting performance.

5. Performance: Precision tolerances and highly controlled surface finishes are where Resin Bond Diamond and CBN wheels really shine. Their remarkable capabilities in these areas are especially crucial in industries like optics, where the tiniest imperfection can lead to significant quality issues.

---

The Master of Surface Finish

Here are the top 8 reasons why the unique characteristics of Resin Bond make it favored across industry applications that require fine surface finishes:

1. Uniform Abrasive Distribution: Resin Bond wheels are manufactured using a carefully controlled process that results in a uniform distribution of abrasive particles throughout the wheel. This uniformity ensures that the wheel removes material evenly across the workpiece, preventing irregularities in the surface finish.

2. Self-Dressing Properties: The self-dressing action of Resin Bond grinding wheels helps maintain a consistent cutting edge, which is essential for achieving a smooth surface finish.

3. Cooler Grinding: Diamond and CBN are already excellent conductors of heat, and resin bonds can be formulated with conductive metals to further aid in heat removal. This improved heat dissipation lessens the likelihood of thermal damage, such as metallurgical changes and micro-cracking, which negatively impact surface quality.

4. Flexibility and Conformability: Compared to Vitrified and Metal Bonds, Resin Bonds are relatively soft and flexible, which is advantageous for contour grinding and achieving intricate shapes. This flexibility allows the wheel to conform to the workpiece's surface, ensuring the consistent contact needed for a smoother finish.

5. Controlled Grit Size and Concentration: Resin Bond wheels can be precisely engineered with specific grit sizes and concentrations of abrasive particles to optimize for surface finish requirements. Finer grit sizes and lower concentrations typically produce finer surface finishes, such as those required by polishing applications.

6. Reduced Wheel Wear: As mentioned earlier, Resin Bonds wheels tend to maintain their shape and cutting efficiency over a longer period than conventional grinding wheels. This lower wear rate contributes to a consistent surface finish.

7. Minimized Wheel Loading: Resin Bond wheels are less prone to loading, which occurs when swarf or material being ground adheres to the wheel's surface. Loading can negatively impact the surface finish, but Resin Bond wheels tend to resist this issue, helping to maintain consistent performance.

8. Wide Range of Abrasive Options: Resin Bond wheels are compatible with a wide range of abrasive materials, including Diamond and CBN. By tailoring the abrasive to the specific material being ground, it further enhances fine grinding efficiency.

---

Areas Where Resin Bond Excels

Resin Bond superabrasive wheels are among the most popular and widely used bond types for a number of other compelling reasons.

1. Versatility: These wheels can be tailored to suit a wide variety of applications, making them indispensable in industries as diverse as automotive, aerospace, medical,and electronics manufacturing.

2. Precision: The accuracy and precision achieved with Resin Bond superabrasive wheels are unparalleled. They produce intricate shapes and finishes with exceptional consistency.

3. Longevity: Thanks to self-dressing properties, Resin Bond superabrasive wheels have a longer operational life compared to conventional abrasive wheels.

4. Reduced Waste: The minimal wear on these wheels results in less material waste, making them an eco-friendly choice for many industries.

5. Reduced Downtime: Less frequent wheel changes and dressing requirements mean reduced downtime and increased productivity for manufacturing operations. Additionally, these tools dress easily for added convenience.

6. Cost-Efficiency: Despite an initial higher cost compared to conventional counterparts, the longevity and efficiency of a Diamond or CBN Resin Bond tool often result in cost savings over time.

7. Hybrid Variants: Hybrid bonds combine characteristics of different bond types. This is especially common with Resin Bond wheels. For example, a hybrid wheel might have a blend of resin and metal bonds to balance precision with heat dissipation.

The Bottom Line

Resin Bond grinding wheels are a testament to advanced materials science and engineering precision. Their ability to cut, grind, and shape materials with unparalleled accuracy and efficiency has made them indispensable in numerous industries, especially in high-precision production grinding applications of hard materials.

These versatile grinding wheels are employed in tasks ranging from centerless and cylindrical grinding to surface and creep feed grinding. They cater to materials as challenging as tungsten carbide, ceramics, and stainless steel, where precision and surface finish are paramount. Resin Bond wheels also excel in cutoff, roll grinding, tool and cutter, saw and knife sharpening, PCD grinding, and surgical tool blade sharpening applications, showcasing their adaptability across the spectrum of manufacturing and fabrication needs. Whether it's the intricate precision required for surgical tools or the robust grinding demands of hardened steel, resin bond grinding wheels are trusted companions for achieving exceptional results.

As technology continues to advance with hybrid bond types, it is likely that Resin Bond superabrasive wheels will play an even more significant role in the quest for perfection in machining and precision grinding. Their adaptability, accuracy, and longevity make them a driving force behind innovation in manufacturing processes and a cost-efficient grinding solution for many industries around the world.

The Story Behind Our Precision Grinding Solutions at Continental Diamond Tool Ltd.

At Continental Diamond Tool Limited, our 40 years of success has been built by delivering the finest custom Diamond Rotary Dressers available in the market. Also called Diamond Rolls, these tools are used extensively in a growing number of grinding operations to primarily facilitate the transfer of highly accurate repeated configurations onto components. What makes a Consort Precision Diamond Rotary Dresser stand out can be summarized in four key aspects: technology, expertise, process, and quality or product excellence. As we have expanded into other product lines, we bring that same commitment to every precision grinding product we produce.

Cutting Edge Technology

In a plunge-style dresser the Rotary Diamond Dresser is mounted onto a spindle of a drive unit which in turn is mounted onto a slideway arrangement that allows the formed periphery of the dresser to infeed into a grinding wheel, thereby transferring the desired shape into it. The form, or configuration, can then be 'ground' on to the component. Plunge dressers are especially accurate for precision grinding as there is no lost form or geometry due to machine movements. Plus, the dressers can be held to submicron levels of accuracy.

Traverse dressing is a grinding wheel dressing technique where the diamond rotary dresser traverses across the surface of the grinding wheel to create a specific profile or shape. Traverse Disc Dressers allow you the flexibility to make profile changes or dress in completely new profiles with the same tool, reducing down time for wheel change overs or roll changes.

INDUSTRY EXPERTISE

Such Industries as the Automotive and Aerospace as well land based Turbine Engine production units employ large quantities of Rotary Diamond Dressers. Typically, within the Aero manufacturing industry, such components as Turbine Blades and Nozzle Guide Vanes as well as Flap Actuating Shafts require their intricate features to be ground with grinding wheels that have been formed with Rotary Diamond Dressers. As can be seen reference is made on our following pages to the many applications within the automotive industry.

CDT Ltd. can offer expertise in the selection of the most appropriate type of Rotary Diamond Dresser by reference to the configuration required and to the grinding machine on which it is to be used. Basically, three processes are employed. Handset Sintered, Random Set Sintered and Reverse Plated. Within each of those categories, selection of diamond type and their placement into the periphery of the Rotary Dresser, plays a major part in determining its operational life and performance. Even before its establishment in 1984, the company’s principals and a large proportion of its employees had many previous years experience in the manufacture of Rotary Diamond Dressers. Bringing with them unique knowledge of the industry, CDT Ltd. — then Consort Precision Diamond — quickly established itself with this one product into the global market of prime and subcontract component manufacturers, earning the respect of competitors and customers alike.

AWARD-WINNING PROCESSES

In respect to the Reverse Plating technique, at Continental Diamond Tool Limited we are particularly proud of the fact that we have been awarded the accolade of winning the BOOST award in the U.K. in 1995 for the design and development of a high speed plating process which dramatically reduced previous lengthy plating times. This achievement gave us a competitive edge against alternative suppliers and satisfied the reduced lead times that customers continue to demand. In the same period, we gained the S.M.A.R.T 1995 award for the development of the electroforming process as an acknowledgement of the reduction in the process time employed in the manufacture of Reverse Plated Rotary Diamond Dressers. CDT Ltd. proudly holds the ISO 9001:2015 Registration Certificate for its Quality Management Systems.

A FOCUS ON PRODUCT EXCELLENCE

The Consort Precision name has become synonymous for outstanding quality and performance in Diamond Rotary Dressers. Since 1984, we have been perfecting the design, development, manufacture, install and maintenance of this advanced dressing technology. This long history with a singular focus has given us the unique ability to provide our customers with the best solution technology can offer. We have the engineering, design, manufacturing and staff resources to supply the highest quality Diamond Rotary Dressers available on the market. Our specialized experience ensures each product we supply is the optimum choice for each individual customer, however demanding and complex the configuration. If an application calls for traverse- or plunge-style rotary dressing, Consort Precision™ Diamond Rotary Dressers are the best tool for the job.

With investment from our parent company, Continental Diamond Tool Corporation, we have expanded our facility in Kinmel Bay to manufacture a wider range of superabrasive products and better cater to a global market. In 2021, an expansion of the Plating lab more than doubled our capacity to produce the high quality tight tolerance reverse plated rotary dressers used by some of the world’s most prestigious corporations. It also paved the way for diversification into electroplated grinding wheels, which we began producing in early 2023. As CDT Ltd. continues to evolve and adapt to the ever-changing technological landscape, we remain committed to delivering innovative solutions and superior products to meet the growing demands of our customers worldwide.

Mastering Precision: How Traverse Diamond Dressing Enhances Grinding Wheel Performance

Precision in manufacturing is the key to producing high-quality components across various industries, from automotive to aerospace, and even in everyday consumer products. One crucial aspect of achieving this precision is the performance of grinding wheels. In precision grinding operations, where the tolerances can be incredibly tight, grinding wheel performance is paramount. Enter the Traverse Diamond Dresser, a type of diamond rotary dresser that plays a pivotal role in ensuring that grinding wheels are in top form. In this blog post, we will delve into the world of Traverse Disc Dressers and explore how they enhance grinding wheel performance.

The Basics of Traverse Diamond Dressing

The Traverse Disc Dresser is an indispensable wheel profiling tool in the realm of precision grinding. Also referred to as Diamond Wheel Dressers, they are designed to dress and shape profile grinding wheels to maintain an optimal condition. The dressing process involves the removal of abrasive material from the grinding wheel's surface, which can become uneven, clogged, or worn over time due to the abrasive grinding process.

Here's how Traverse Disc Dressers work their magic:

1. Material Removal: These dressers feature a wide range of diamond sizes and grades to achieve the desired dressing condition. As the rotary diamond dresser traverses across the grinding wheel's surface, it precisely and efficiently removes small amounts of abrasive material. This effectively 'cleans' the wheel, restoring its cutting ability.

2. Wheel Truing: One primary function of Traverse Disc Dressers is truing the grinding wheel. Over time, grinding wheels can develop irregularities, affecting the precision of the grinding process. The dresser ensures that the wheel runs true and maintains a consistent, flat or cylindrical shape, depending on the application.

3. Form Dressing: In precision grinding, some applications require intricate shapes or profiles to be ground onto workpieces. Traverse Disc Dressers can be employed for form dressing, which shapes the grinding wheel to match specific profiles with utmost precision.

Achieving Superior Grinding Wheel Performance

Now that we understand the role of Traverse Disc Dressers let's explore how these wheel profiling tools enhance grinding wheel performance:

1. Consistency is Key: Precision grinding demands consistency. Traverse Diamond Dressing ensures that the grinding wheel profile remains uniform in shape, minimizing variations in the workpiece's finish and dimensions. This consistency is essential for meeting tight tolerances.

2. Optimized Material Removal: Dressing the wheel not only ensures precision but also optimizes material removal rates. It enhances the wheel's cutting ability, reducing heat generation and the risk of burning the workpiece—a common issue in precision grinding.

3. Reduced Scrap Rates: With a properly dressed grinding wheel, the likelihood of producing defective or out-of-spec parts is significantly reduced. This translates to lower scrap rates and higher yields, ultimately improving the bottom line.

4. Versatility: Traverse Disc Dressers are versatile tools suitable for various grinding applications. Whether you're grinding metals, ceramics, or other materials, these dressers can be adapted to meet your specific needs.

5. Flexibility: Change parts/profile shapes frequently?  Traverse Disc Dressers allow you to quickly and easily make profile changes or dress in completely new profiles without making grinding wheel changes, saving you down time for wheel change overs and/or roll changes.

Applications for Traverse Disc Dressers

Traverse Disc Dressers play a pivotal role in a multitude of precision-driven industries. These grinding wheel truers are essential for maintaining and shaping grinding wheels, ensuring that precision grinding processes yield consistent and accurate results. Here's a succinct overview of how key industries rely on Traverse Disc Dressers:

Automotive: Crucial for precision grinding in tasks like crankshaft and camshaft production, gear manufacturing, and engine component fabrication.

Aerospace: Used in grinding operations for aircraft components and jet engine parts, where precision is paramount.

Tool and Die Making: Maintains the sharpness and precision of cutting tools, including end mills, drill bits, and punches.

Medical Device Manufacturing: Ensures precision in the production of surgical instruments, orthopedic implants, and dental tools.

Bearings and Bearing Components: Shapes and maintains grinding wheels to ensure the accuracy of bearing components.

Cutting Tool Manufacturing: Essential for achieving precise tool geometries and cutting-edge profiles in tools like inserts and taps.

Oil and Gas: Involved in precision grinding for drilling equipment, pumps, and valves, vital in this sector.

Metalworking: Used in the production of gears, shafts, and machine components to meet precision requirements.

Die Casting and Foundry: Maintains and shapes grinding wheels to finish cast components with tight tolerances.

Renewable Energy: Supports precision grinding operations for components in renewable energy technologies like wind turbines and solar panels.

These industries rely on Traverse Disc Dressers for precision and consistency in their manufacturing processes, making them essential tools for achieving the highest levels of accuracy in precision grinding operations.

Types of Traverse Disc Dressers

Traverse Disc Dressers come in distinct types, each designed for specific applications. They can be made with a wide range of diamond sizes and grades, with CVD (chemical vapor deposition) stones, or a combination of the two, to achieve the desired dressing condition.

1. Electroplated: Electroplated Traverse Disc Dressers are known for their short lead times and open and aggressive structure allowing for high removal rates with similar performance at a lower cost.

2. Metal Bond: Metal bond Traverse Disc Dressers offer flexibility with a range of bond systems and abrasives to custom fit the application and provide a balance of durability and precision, making them suitable for a wide range of grinding operations.

3. Sintered: Sintered Traverse Disc Dressers offer exceptional durability and precision and are ideal for applications involving hard and abrasive materials with tight profile tolerances.

4. Reverse Plated: Reverse Plated Traverse Disc dressers stand out due to their unique construction, which allows for unmatched precision and efficiency in shaping grinding wheels. They offer benefits such as reduced dressing time, extended wheel life, improved surface finish, and versatility, making them a valuable asset for industries requiring the highest levels of accuracy in their grinding operations.

It's worth noting that CDTUSA manufactures all types of traverse dressers except Reverse Plated, which will be added to our lineup next year. CDT Limited in Europe (previously Consort Precision Diamond) specializes in Reverse Plated, as well as the other types of diamond rotary dressers. When it comes to grinding wheel truers, our dedicated teams are ready to assist you. Feel free to reach out for a free quote, and let us help you achieve precision and excellence in your grinding operations.

Understanding the Distinction Between CBN and Aluminum Oxide Abrasives

Are you ready to explore the fascinating world of abrasives? In manufacturing, we often encounter Superabrasives and Conventional abrasives. In the Superabrasives corner, we have Diamond and Cubic Boron Nitride (CBN), and their common Conventional abrasive counterparts are Silicon Carbide and Aluminum Oxide. Each serves a specific purpose. What makes CBN and Aluminum Oxide stand out is their exceptional ability to tackle those stubborn steels and metals that can't stand Carbon.

In this blog, we'll explore the properties and applications of CBN and Aluminum Oxide abrasives. Discovering their unique characteristics will help you choose the right abrasive for your specific machining needs, ensuring efficiency and top-notch results. Whether you're working with hardened steels or softer metals, the right abrasive is the key to achieving your desired outcome in grinding and machining. So, let's dive in and unlock the true potential of CBN and Aluminum Oxide abrasives.

What is CBN?

CBN is a synthetic Superabrasive known for its incredible hardness, high thermal conductivity, and thermal stability. Originally released with the trade name Borazon from GE Superabrasives, its cubic crystal lattice structure is similar to Diamond, giving it remarkable abrasive properties. With a hardness close to 10 on the Mohs scale, CBN excels in machining tough materials that require precision grinding. Its chemical composition and high thermal stability prevents chemical reactions and premature breakdown under high temperatures, when grinding ferrous metals and high-temperature alloys. What's more, because CBN doesn't react with ferrous materials, it doesn’t alter or change their properties resulting in longer life in use when ground with CBN.

CBN is a game-changer when grinding hardened ferrous alloys or super alloys that are sensitive to heat. It efficiently grinds hardened steels while maintaining accuracy and surface finish. Plus, it's a favorite for grinding ferrous metals like cast iron and stainless steel, ensuring clean and precise results without chemical alterations. CBN is a must-have tool for achieving precise and efficient outcomes in critical machining tasks.

What is Aluminum Oxide?

Aluminum Oxide, also known as alumina, is a versatile Conventional abrasive. With high hardness and toughness, it is available in various grit sizes, making it perfect for a wide range of machining and finishing applications. Though not as hard as CBN, Aluminum Oxide is fantastic for soft metals, wood, and non-ferrous materials. While it may not match the precision of Superabrasives, it's still a reliable choice for many tasks.

In the machining industry, Aluminum Oxide is the go-to for grinding soft metals like aluminum, brass, and copper. It performs beautifully with non-ferrous materials such as bronze and titanium, without causing any chemical interactions. Its role in achieving desired surface finishes across various industries, from automotive to aerospace, is unparalleled.

Key Differences Between CBN and Aluminum Oxide Abrasives

While CBN and Aluminum Oxide both play significant roles in grinding and machining operations, they have many distinct properties that set them apart.

Crystal Structure and Hardness: CBN's crystal lattice structure is similar to Diamond, resulting in exceptional hardness and wear resistance. Aluminum Oxide, while still hard, has a lower hardness than CBN, making it more suitable for soft metals and certain alloys.

Heat Resistance and Thermal Conductivity: CBN exhibits superior heat resistance and thermal conductivity compared to Aluminum Oxide, making it perfect for grinding high hardness and heat sensitive alloys.

Material Compatibility and Reactivity: Both CBN and Aluminum Oxide are chemically inert with ferrous materials whereas Diamond and Silicon Carbide are not, thus why they are the abrasives for ferrous metals.

Cost and Practicality: CBN grain costs significantly more than Aluminum Oxide grain, resulting in higher grinding wheel prices. Because of higher hardness and better thermal conductivity, CBN wheels can provide lower grinding costs in applications where high workpiece hardness and thermal properties need to be maintained. In cases of grinding soft steels and low volume production, the lower wheel price of Aluminum Oxide makes it a more competitive option.

Safety Considerations and Handling

Whether you choose CBN, Aluminum Oxide, or another solution for your abrasive, ensuring safety during grinding and finishing processes is essential. Proper machine guarding, eye and respiratory protection, proper dust/mist extraction, and careful handling and storage of abrasives are crucial to protect workers and maintain a clean and safe work environment.

Selecting the Right Abrasive for Specific Applications

Choosing the right abrasive for your specific machining needs is vital to achieving optimal results. Making an informed decision will ensure efficient, accurate, and cost-effective grinding and finishing processes. Some factors to consider include:

Workpiece Material Characteristics: Soft metals like aluminum, brass, copper, and mild steels  may need moderate hardness abrasives like Aluminum Oxide to prevent excessive material removal, while harder materials like hardened steels and high-temperature alloys such as inconel and hardened Stainless Steel  require abrasives with superior hardness and high thermal conductivity like CBN for precise and efficient cutting and grinding.

Machining Operations and Efficiency: Superabrasives like CBN are preferred for high-precision tasks where tight tolerances and maintaining material properties are paramount, while conventional abrasives like Aluminum Oxide offer lower cost solutions for general grinding of mild steel and soft metals.

Surface Finish and Material Removal Rates: Superabrasives like CBN excel in production applications of hardened steels and Superalloys that are sensitive to heat, , while conventional abrasives like Aluminum Oxide are effective in low volume applications and for grinding of soft metals.

Tooling and Machinery Considerations: Abrasive selection also needs to account for machinery and tooling capabilities.  The truing and dressing of Superabrasive and Conventional Abrasive grinding wheels can be different and require different tools (stationary or rotary dressers of different configurations).  Because of the difference in hardness between CBN and Alumina, Alumina being much lower, the amount of grinding debris resulting from wheel wear during grinding can be 100-300 x’s greater with the conventional wheel, which in turn needs to be disposed of.  .

Both CBN and Aluminum Oxide abrasives offer distinct advantages in grinding and machining. Considering their unique properties with specific application requirements will lead to efficient and precise processes, ensuring optimal results and safety in the workplace. And if you ever need assistance, our grinding experts at CDT are here to help. Whether it's Superabrasives or Conventional abrasives, we can help find the perfect solution for your process.

Superabrasive Grinding Technology for the Ceramic Industry

The rapid growth of ceramic and carbide components in industries such as Automotive, Aerospace, Medical, and Electronics has created new challenges for grinding professionals. The hardness, abrasiveness, and brittle nature of ceramics and carbides make them difficult to grind efficiently. Yet advancements in superabrasive grinding technology have paved the way for improved grinding processes and reduced cycle times for those that invest in new custom technology. In this article, we explore the transformative impact of custom superabrasive grinding products on the ceramics industry, highlighting the benefits they offer and the cutting-edge technologies driving these innovations.

Overcoming Grinding Challenges in the Ceramics Industry

Ceramic and Carbide materials pose unique challenges when it comes to grinding due to their unique hardness and abrasive properties. Traditional metal bond and resin bond grinding wheels have been the go-to solution for grinding these materials. However, advancements in CNC grinding equipment and the introduction of new bond systems have revolutionized the way ceramic and carbide components are ground.

See Brochure

In different industries like electronics, optics, aerospace, and advanced manufacturing, people are using carbide and ceramic coatings to make components last longer and better at handling heat. Two common ways to add these coatings are HVOF (High-Velocity Oxygen Fuel), which uses high-speed flames to spray the coating onto surfaces, and HVOC (High-Velocity Oxygen-Fuel Cold Spray), which works at lower temperatures with fast-moving gas. Another method is Chemical Vapor Deposition (CVD), where a thin layer of material is deposited on a surface through chemical reactions in the vapor phase. Using CVD or HVOF/HVOC can make components longer lasting and more wear resistant.

The inclusion of carbide or ceramic layers necessitates special consideration during the grinding process because of the inherent hardness and abrasive properties of these materials. Superabrasive grinding wheels offer superior performance in grinding these materials by reducing grinding forces, lowering power consumption, and minimizing subsurface damage. These innovative grinding products are particularly effective in reducing grinding cycle times and reducing scrap, resulting in significant cost savings and enhanced productivity.

Advances in Superabrasive Grinding Technology

The advent of multi-axis CNC grinding with Rotary Dressers has automated grinding processes, increasing efficiency and accuracy. Spindle & High-Pressure Coolant systems have improved the delivery of coolant to critical grinding areas, optimizing swarf removal and improved the cooling and lubrication during the grinding process. High-speed grinding spindles enable a wider range of bond technology and wheel sizes to be used for ID and smaller part grinding.

New "Cutting Tool" designs, such as slotting, high porosity bonds, coolant holes, and CNC adaptors for improved rigidity, have improved tool life and performance. These designs enhance coolant flow, chip evacuation, and overall tool effectiveness, contributing to longer tool life and reduced downtime.

Innovative bond systems have been developed to address the unique challenges of grinding ceramic and carbide materials. These new bonds lower grinding forces, reduce power consumption, and lead to faster cycle times. They also minimize subsurface damage resulting in lower scrap rates while enhancing the quality and integrity of the finished components.

Superabrasive Grinding Products for Ceramic & Carbide Components

CDT's superabrasive solutions deliver significant benefits, including a reduction in grinding forces by 30% or more (compared with resin & metal bonds), reduction in cycle times by up to 50%, and significant reduction in scrap rates on these critical and costly components. These advancements help manufacturers optimize their grinding processes, increase productivity, and reduce costs.

Continental Diamond Tool (CDT), a leading provider of superabrasive solutions, offers a comprehensive range of grinding products designed specifically for the ceramics & carbide industries. Their products are compatible with major industry equipment manufacturers, including Studer, Kellenberger, Danobat, Walters, ANCA, Junker, Okuma, Koyo, USACH, Lapmaster, Peter Wolters, SpeedFam, Stahli, Supfina, and many more. CDT also offers advanced custom tool designs, such as cross cutters and hole drilling with flat bottom drills, to address specific grinding requirements. Their expertise extends to a wide range of equipment, including round tools for Anca, Haas, ITM, Normac, Rollomatic, Star, and Walters, as well as inserts for Agathon, Coborn, EWAG, Waida, and Wendt. Additionally, CDT has created surface grinders for Arter, BLOHM, Brown & Sharp, Chevalier, ELB, and Magerle, as well as Blanchard grinders for Blanchard, Bourn & Koch, and DCM.

Superabrasive grinding products have revolutionized the ceramics & carbide industry, overcoming the challenges presented by the high hardness and abrasive nature of these materials. With reduced grinding forces, faster cycle times, and reduced scrap rates, manufacturers can achieve greater efficiency, productivity, and cost savings. Continental Diamond Tool's advanced superabrasive solutions provide tailored grinding products for a wide range of equipment, enabling manufacturers to optimize their grinding processes and achieve exceptional results. As industries continue to evolve to use more ceramic & carbide materials, the use of superabrasive grinding products will undoubtedly play a crucial role in meeting the growing demand for efficient production of these components.

5 Common Questions About Industrial Diamonds For Grinding

1: What are industrial diamonds, and how are they used in grinding wheels?

Industrial diamonds can be either synthetic diamond or natural diamond and are specifically processed for industrial applications, rather than for jewelry.

Industrial diamonds are used in grinding wheels as an abrasive that removes material from a workpiece through friction and cutting. When the grinding wheel rotates against the workpiece, the diamond particles (abrasives) efficiently remove small particles of the workpiece – resulting in geometry, size, and finish desired.

Because diamond is the hardest known material, grinding wheels with diamond abrasives are commonly used in hard material applications that require high precision and accuracy such as in the aerospace, automotive, medical and semiconductor industries. CDT has experience working with grinding operations in all of these areas.

2: How are industrial diamonds manufactured?

Natural diamonds have been used for a long time in industrial grinding. They are mined from the earth and transported to a plant for processing. Through a system that includes x-ray machines and hand sorting, the gem quality diamonds are separated from industrial diamonds. These small, lower-quality stones, otherwise known as ‘boart,’ can be used in equipment such as grinding wheels, drill bits, and dressing tools.

Synthetic industrial diamonds used in grinding wheels can be made in one of two ways:

• High-pressure and high-temperature (HPHT)

• Chemical vapor deposition (CVD)

In the HPHT method, diamond-creating materials are put under high pressures and high temperatures to make it form into a diamond. In the CVD method, diamond-creating materials are put in a vacuum chamber where carbon gasses are then added to make it form into diamond.

Whether naturally or synthetically sourced, the industrial diamonds are then crushed, milled, cut, shaped, and polished to customizable sizes and shapes. Then, the particles are bonded together to form a grinding wheel or cutting tool, typically using metal, resin, vitrified materials or electroplated in a single layer onto a metallic substrate.

3: How do the properties of industrial diamonds affect the performance of grinding wheels?

Industrial diamonds are valued for their extreme hardness, wear resistance, and thermal conductivity. All of these impact the performance of a grinding wheel.

Extreme Hardness:

Diamonds are known for their extreme hardness because they are made up of carbon atoms that are held together in a cubic crystal lattice structure. You can think of it like a brick wall, where the precise arrangement and spacing of the bricks represents the arrangement of atoms in the cubic crystal structure. Like a brick wall, diamond is strong and stable, making it difficult to break or become deformed.

Because diamond is the hardest known material, it is not readily scratched by other materials. Instead, it does the scratching.  Because of the high strength of the carbon bonds, Diamond has the best wear properties of all abrasives unless chemically attacked by materials that react with carbon.

This gives grinding wheels the ability to precisely cut through and remove material from other hard substances like ceramics, glass and non-iron-containing metals with very precise geometries and dimensional tolerances.

Wear Resistance:

A diamond's wear resistance refers to its ability to maintain sharp edges and cutting ability for longer, which results in longer-lasting grinding wheels that don’t need to be replaced as often.

Diamond particles can withstand high pressures generated during the grinding process – a crucial aspect of grinding that can cause other abrasive options to break down. Whereas the wear-resistant nature of a diamond abrasive maintains a durable, precise size and finish.

Thermal Conductivity:

Diamonds have the highest thermal conductivity of any known material, which is ideal for grinding due to the heat generated by the friction that occurs during the grinding process. Heat can cause abrasive particles in the wheel to become dull and less effective at cutting, as well as cause thermal damage to your workpiece.

Diamonds can conduct heat away from the grinding area more effectively than other abrasive materials. This keeps it cooler, protecting the material being ground from thermal damage and preventing the abrasive from becoming dull.

4: What are the advantages and disadvantages of using industrial diamonds in grinding wheels compared to other abrasive materials?

Advantages:

Diamond is the hardest known material due to it’s strong covalent bonds between carbon atoms and perfect crystal symmetry.  Because Diamond is harder than all other materials it is the best choice for grinding and wear resistance.  Other abrasives are softer than diamond and therefore do not last nearly as long.  Secondly, Diamond also has the best thermal conductivity and therefore removes/dissipates most effectively the heat generated during grinding.

All of this makes diamond an advantageous choice as an abrasive because it will provide a longer-lasting durability, an improved precision, and a better quality finish.

Disadvantages:

Because of its high hardness, it also means that diamonds can’t be easily shaped or molded into different forms. Dressing of diamond wheels is done with Diamond tools, and with Diamond on Diamond, dresser life is low when compared with other abrasive types.  Secondly, Diamond grinding wheels are not recommended when grinding ferrous metals as a chemical reaction between Carbon (Diamond) and the metal is possible and results in changes of the material properties of the metal and premature wear of the Diamond grinding wheels, both of which can be detrimental.  Therefore, diamond is typically suggested for use in specialized applications for grinding of hard materials such as Ceramics, Carbides, and glasses.

5: What are the latest trends and advancements in industrial diamond technology for grinding wheels?

One of the latest trends in industrial diamonds is the increasing use of synthetic or man made diamonds. Diamonds that are grown in a lab are as real as diamonds mined from the earth. They are identical to natural diamonds in every way, except that they are created in a lab and the specific material properties of the Diamond can be tailored to specific applications..

As this process has gotten more efficient, man made diamonds can now be sourced cheaper and more readily than natural diamonds. Diamond grinding products are becoming more economically viable for a growing number of industries. CDT uses both natural and synthetic diamonds in its superabrasive products.

Another advancement in industrial diamond grinding technology is the creation of hybrid bond grinding wheels. Hybrid wheels combine different types of bond to adhere the abrasive material, such as diamond, to the grinding wheel and achieve superior grinding performance.

Traditionally, diamond grinding wheels use one of a handful of bonding agents to adhere the superabrasive material to the grinding wheel. Bonding options include:

• Electroplating

• Resin bond

• Metal bond

• Vitrified bond

Each of these bonding options have different characteristics which result in different pros and cons for the grinding process. You can learn more about the different bond types here.

By combining bonds, hybrid wheels can be tailored to the needs of specific grinding applications, resulting in higher efficiency and reduced costs. CDT specializes in cutting edge, customizable hybrid bonds using diamond abrasives to provide superior results for our customers. You can learn more about our hybrid bonds here.

Industrial diamonds are a crucial component in many grinding processes, and they continue to play a vital role in the manufacturing industry. Because of their ideal thermal conductivity, wear resistance, and hardness, the technology will continue to advance to make the most use out of this favorable material. It is safe to say that industrial diamonds are not going away anytime soon, and their importance in the manufacturing industry will only continue to grow from here!

If you are wondering if diamond grinding wheels or tools would be a good fit for your specific application, contact CDT for a free quote.

CDT Expands Diamond Rotary Dresser Production

For companies in need of grinding wheel dressing, conditioning, and shaping, finding a high quality and cost effective supplier for custom dressing solutions is even easier!

Continental Diamond Tool is proud to announce that we’re expanding our capabilities to make custom Diamond Rotary Dressers (also known as Diamond Rolls) in our dressing product line.

Dressing tools are a necessary aspect of maintaining the natural wear and tear that occurs with superabrasive grinding wheels. When your abrasive becomes dull and ineffective due to particle buildup, it is recommended that you use diamond dressers to clear off the particles and make your grinding wheels perform like new again.

While many tool and cutter grinding shops and other manufacturing facilities use stationary dressers to get that job done, more and more industries are finding uses for diamond rotary dressers — and for good reason!

As industries work with more and more advanced and complex engineering configurations, Diamond Rolls are the clear, superior choice for these applications … but why?

Simple. Diamond Rolls:

• Have precision profiles and geometry to match your specific needs

• Are designed for your specific needs, surface finish, removal rates, time savings

• Come in all shapes and sizes, from simple traverse dress rolls to complex profiles

Not only does it make way for excellent sharpening and fine finishes, it’s cost effective too.

CDT currently offers the following types of Diamond Rolls:

• CVD dressers

• Sintered Rotary Dressers

• Reverse Plated Rotary Dressers

Diamond Rotary Dressers are commonly used in the following industries:

• Aerospace

• Automotive

• Biomedical

• Knives and Blades

• Bearing

Whether you are in an industry that’s looking for one of the dressing products above — or if you want to work with our engineers to develop something new— CDT is excited to serve your needs with the best possible up-and-coming technology for getting the job done right.

CDT has been in the business of providing solutions for sharpening and refinishing of superabrasive grinding wheels with Stationary Diamond Dressers since our start in 1973. In 2018, we added Diamond Rolls to our dresser line through our acquisition of Consort Precision Diamond in the U.K. who joined us with a solid reputation for making major technological advancements in rotary dresser technology.

Now, after upgrades made in late 2022, Continental Diamond Tool has capabilities to produce many configurations of custom Diamond Rotary Dressers at our U.S. facility in New Haven, Indiana. Call us or complete our contact form for details.

How to Extend the Life of Your Electroplated Grinding Wheel

CDT offers what’s called the “Strip and Replate” Program, designed to give our customers the highest quality grinding wheel abrasives for the longest time possible, in the most cost effective way for the customer (more on this in a moment)...

First, let’s cover when you’ll want to opt for this program, and how it works.

Stripping and replating a grinding wheel refers to the process of removing the old, worn-out abrasive material from the surface of a grinding wheel and replacing it with new abrasive material.

When customers opt in for this program, we work with you to create customized tooling that you will be able to use and then bring back to CDT for us to return it to “like new” condition after it begins to wear. This keeps your wheel fresh and performing at optimal levels without having to buy new.

When To Strip and Replate?

There are many reasons why you may need to replace your wheel with new abrasive, including:

• The particles on the surface of your abrasive get clogged (potentially from metal shavings or debris from the grinding process)

• Your wheel becomes dull from the worn out abrasive

• You need to switch from grinding one material to another, and the new material requires a different type of abrasive to be put on your wheel

• The grinding wheel has worn down unevenly, causing vibrations and reducing your wheel’s effectiveness

How Does The Process Work?

CDT is able to provide high quality strip and replate services through strip technology that will remove the remaining abrasive on your worn down wheel without damaging the surface finish of the core.

Electroplating involves depositing a thin layer of metal and abrasive particles onto the surface of a grinding wheel by using an electrical current in an electrolytic plating solution.

When a grinding wheel has reached its life, we remove the old abrasive material on your wheel by soaking the wheel in a chemical solution that will safely dissolve the deposited plating without damaging the integrity of the core.

Once the old deposit and abrasive have been removed, we apply a new layer of abrasive material through the electroplating process.

After the new abrasive material has been applied, the grinding wheel is re-balanced to ensure you continue to have smooth operation and optimal performance with your returned “like new” wheel.

When is An Electroplated Grinding Wheel The Best Choice?

Electroplated grinding wheels are considered the superior choice for applications that require complex shapes or geometries. Some specific applications include metal cutting tools, saw and knife sharpening, PCD grinding, and surgical tool blade sharpening – among others.

They’re used in a wide range of industries, including metalworking, woodworking, glass and ceramics, aerospace, automotive, medical, and electronics manufacturing.

Common materials that are compatible with an electroplated diamond grinding wheel include:

• Cemented carbide

• Glass

• Ceramics

• Fiberglass

• Plastics

• And more

Whereas common materials that are compatible with an electroplated CBN grinding wheel include:

• Die steel

• Hardened carbon steels

• Hardened stainless steels

• Alloy steels

• Aerospace alloys

• And more

When you add in the ability to strip and replate, it makes electroplating a superior choice in many ways:

1. It provides a more consistent and uniform distribution of abrasive particles on the surface of your grinding wheel, which can help ensure consistent grinding results and prevent uneven wear in the future.

2. Electroplating creates a strong bond between the abrasive particles and the wheel substrate, which helps prevent the abrasive from separating or shedding from your wheel during use.

3. It can be used to apply a wide variety of abrasive materials, including diamond, cubic boron nitride (CBN), and various types of abrasive grains – and it can be used with both brittle materials and soft metals.

4. Stripping and replating an electroplated grinding wheel is a relatively quick and straightforward process because they are a single layer wheel. It also allows for precise control over the thickness of the abrasive layer, making it an ideal choice for achieving any customizations you may need for your wheel.

5. Electroplated wheels can withstand heavy use and provide consistent grinding performance. They don’t need to be reconditioned as frequently as other types of grinding wheels, making them a more cost-effective choice in the long run.

Overall, opting for an electroplated grinding wheel to be reconditioned and used again through the CDT “Strip and Replate” Program can result in 40% more in savings, with consistent performance results, rather than opting for brand new plated products.

If you’re ready to learn how CDT can work with you for a customized electroplated grinding wheel that qualifies for our “Strip and Replate” Program, click the button below to request a quote!

The CDT technical team is ready to provide abrasive solutions to your questions that will increase your performance while reducing waste.

Meet The Next Generation In Hybrid Bond Technology: Ultra High Performance Grinding For The Cutting Tool Industry

At Continental Diamond Tool we are proud to announce that we have officially unveiled our latest breakthrough technology in hybrid bond products – the EVO Hybrid Bond – at the much anticipated Precision Machining Technology Show this past April 2023.

What is EVO Hybrid Bond?

A game-changer in the precision grinding industry, EVO is a custom-designed bond that delivers ultra-high performance results that are impossible for our competitor’s standard Resin Bond wheels to match.

This bond is a new and improved version of CDT's Resin Hybrid Bond, designed specifically to cater to the needs of Tool and Cutter Grinding.

One of the key benefits of EVO is its superior performance that helps produce high-quality cutting tools faster and more efficiently than its past versions.

The bond is uniquely formulated to achieve faster cycle times without compromising on the wheel edge, making it an ideal choice for:

• Flute from solid

• Regrind

• Gash and end work

• And relief

What are the benefits of EVO Hybrid Bond?

When you opt for CDT’s EVO Hybrid Bond technology, you can expect superior results in both form retention and surface finish because of its free cutting action.

Additionally, the EVO bond is self-sharpening. This type of technology ensures the life of your wheel is longer-lasting, as is the dressing interval.

It can also withstand much higher temperatures while still maintaining its stability, which makes high material removal rate not only possible, but incredibly precise.

Because CDT’s EVO Hybrid Bond offers excellent heat dissipation capabilities (while ensuring low and consistent power consumption) it enhances your overall efficiency and productivity of the grinding process.

It’s also a much more sustainable option. The wheel profile lends itself to a longer-lasting type of technology that reduces your grinding process costs in the long-term.

What sets EVO Hybrid Bond apart from the competition?

Beyond all of the benefits listed above, what sets EVO apart from other superabrasive grinding products is its unique blend of Resin Bond and Metal Bond.

Available exclusively through CDT, this customizable type of bond is designed specifically to deliver cutting edge results that standard wheels cannot hope to compete with.

For the high precision cutting tool industry, EVO is a long-awaited solution to many common grinding challenges.

The bond offers a faster cycle time, less dressing, and greater performance. It is an ideal solution for those looking to improve their grinding process and achieve their goals.

At CDT, we are committed to providing the latest technology solutions to help the precision cutting tool community overcome their machining challenges. EVO Hybrid Bond is a testament to our commitment, and we are confident that it will transform your grinding process and help you stay ahead of the competition.

How To Select The Right Bond Type

Congratulations! If you are on this website, you’ve probably come to the conclusion that a superabrasive grinding wheel will be the best solution to your project’s needs. If you are still considering the pros and cons of the different types of grinding products, check out this article that explains the differences between superabrasive and conventional grinding wheels.

Once you’ve decided you need a superabrasive solution for your grinding application, what’s the next step?

SELECTING YOUR BOND TYPE

The bond acts as the glue that keeps the abrasive grains in your grinding wheel connected. The bond's strength, also known as its hardness, determines how well the wheel can handle different materials.

Harder bonds are typically recommended for softer materials and vice versa. There is also the option to create custom hybrid bonds that are specially formulated to possess unique characteristics that will better support your more specific needs.

A grinding wheel expert can help you narrow down your selection, as there are many different bond types.

Let’s go over the common ones:

• Resin Bond

• Metal Bond

• Vitrified Bond

• Electroplated Bond

• Hybrid Bond

---

RESIN BOND

Resin bonds are the most widely used bond type in superabrasive grinding wheels. Simply put, they are grinding wheels held together with a plastic bond.  They are made from synthetic resins, such as phenolic or epoxy, which is used to hold the abrasive in place.

Mostly, these types of grinding wheels are formulated and blended as powders which are then cast and hot pressed in steel molds of the desired size and shape of grinding wheel desired.  The specific properties of the bond are determined by the specific resin and additives to get the desired mechanical and grinding properties.

Because of Resin Bond’s resilience and toughness, these grinding wheels tend to be:

• Easy to use

• Versatile across a broad range of materials & applications

• Relatively inexpensive when compared with other superabrasive grinding wheels

---

METAL BOND

Metal bonds are, as the name suggests, made from metals – such as bronze and iron. Like Resin Bond products, Metal Bond grinding wheels are blended as powders and hot pressed in high temperature alloy or graphite molds as the processing temperature is much higher than resin.

Metal bond is the hardest of the bond types. Because of this, most Metal Bond grinding wheels are made with diamond, the hardest superabrasive, and are used on especially hard materials such as glass, ceramics, and carbides. Between the inherent hardness of the bond and the hardness of the materials being ground, these wheels generate the highest grinding forces and usually require special dressing or conditioning steps during use.

Benefits of Metal Bond grinding wheels include:

• Resistance to wear

• Longest wheel life

---

VITRIFIED BOND

Vitrified (or more appropriately known as “glass” or “ceramic”) bonds are different from resin and metal bonds in that they have both a mechanical bond like the others, but also a chemical bond between the abrasive (either dIamond or CBN) and the bond itself.  Most commonly, these bonds are engineered with porosity and are “cold pressed” and sintered as opposed to hot pressed.

While the actual glass/ceramic bond is technically harder than metal bonds, the porosity levels make the function better in grinding as the porosity efficiently removes grinding debris (swarf) and brings coolant into the point of grinding. Because of the porosity of these grinding wheels, they are also more readily able to be dressed and formed into specific desired geometries.

Because Vitrified bonded grinding wheels have lower grinding forces and the ability to be readily dressed with rotary dressers, this type of bond is ideal for high volume production grinding applications of hard materials that can most benefit from the:

• Lower grinding forces

• Faster grinding cycles

• Lower scrap rates

In the case of CDT’s VIPER Vitrified Bond grinding wheels, we have enhanced the bond strength over traditional Vitrified Bonds, coupled with a porous vitrified structure, to more perfectly grind some of industry’s hardest materials like silicon carbide, aluminum oxide, glass, carbide, and others. Our VIPER Bond system provides enhanced dressability, lower grinding forces, and shorter grinding cycles over traditional Vitrified Bond systems.

---

ELECTROPLATED BOND

An electroplated bond is a metallic bond (typically nickel for superabrasive grinding wheels) in which a single layer of abrasive is adhered or bonded onto a metallic core through a deposition process.  Like all electroplating processes, metallic material is pulled from solution and deposited onto the substrate, encapsulating the abrasive onto the substrate in the same form as the substrate.

Like the other bond types, both diamond and CBN superabrasives are used depending on the application.  Because electroplating is a liquid process, complex shapes and geometries are more readily achieved and generally don’t require dressing when in use.

Another benefit to using electroplated grinding wheels (also referred to as just ‘plated grinding wheels’) is that they are single layer and used wheels are able to “stripped” or reverse plating process and the substrate/core can be reconditioned and used again resulting in potential savings of as much as 40% over new plated products.

To recap, Plated grinding wheels:

• Generally don’t require dressing

• Can be designed in complex shapes and geometries

• Can be reconditioned and used again for cost savings over the life of the wheel

---

HYBRID BOND

A hybrid bond is a combination of two or more different types of bonds and/or processing methods to create a “Hybrid” that encompasses enhanced properties to achieve better performance in grinding for a specific application.

For example, resin and metal bonds have successfully been combined into a single wheel in our EVO Hybrid Bond grinding wheels designed for the cutting tool industry. In this hybrid resin/metal bond wheel, the hard metal bond is softened to make it more user friendly while maintaining long life.

New hybrid bonds and technologies continue to be developed to bring enhanced grinding performance to specific production grinding processes.

---

NEXT STEPS

To dig deeper into why different types of materials require different grinding solutions, check out our previous blog Why Different Materials Need Different Grinding Wheels.

Grinding is a complex process that requires a total “systems” approach. Your grinding solution needs to encompass; the grinder/machine, dressing/truing requirements, material, coolant, and the grinding wheel.

If you’re ready to move forward with a quote or investigate the advantages of a certain bond type for your specific application, contact us to speak with our team of expert engineers that will help answer your questions and get you started.

7 Reasons Why Vitrified CBN Grinding Wheels Surpass Conventional Grinding Wheels

A vitrified CBN grinding wheel is a superabrasive grinding wheel made from a Cubic Boron Nitride abrasive in a porous – or “vitrified” (ceramic) – bond.

Vitrified CBN Grinding wheels are the most cost effective solution for production grinding of ferrous metals and aerospace alloys, and offer far superior performance when compared with conventional abrasive grinding wheels.

Especially for those in industries such as:

• Aerospace

• Automotive

• Bearing

• Medical

• Gears

• Mold & Die

• Round Tools (drills, reamers, taps, etc)

• Cutting Tools

So why exactly is that?

There are 7 critical reasons why making an upgrade to a CBN grinding wheel can make a huge difference in your industry.

1. 100 - 300x The LifeSpan

CBN abrasive is the second hardest material known to man and is 2 ½ times harder than Aluminum Oxide. Because of its high hardness, the CBN crystals offer 100-300 times the lifespan when compared with traditional grinding wheels.

While Vitrified CBN grinding wheels may cost up to 10 times that of a conventional wheel, the extended wheel life far exceeds the initial wheel cost, making it more cost effective. You get what you pay for – and this is definitely one of those products where you’ll quickly see the difference in its longer lasting abilities as compared to your old grinding wheels.

(We’d even argue that once you’ve used a CBN grinding wheel, it’s hard to go back – it’s just that big of a difference).

2. Reduced Thermal Damage

Because CBN abrasive has almost 50 times the thermal conductivity of conventional abrasives, it transfers the heat generated from the grinding process away from the workpiece, rather than being absorbed by the workpiece.

Combining the high thermal conductivity of CBN with the porous vitrified wheel structures, most heat is efficiently removed through the wheel and coolant, preventing heat damage to your workpiece.

With efficient removal of heat, your workpiece won’t be subject to thermal degradation or changes to the material properties – which is very important for improved wear and life of each  component.

3. Optimize Your Grinding Process

With high life and improved thermal properties, Vitrified CBN can be pushed harder during grinding, and decreased grinding cycle times are able to be achieved.

As a result, the grinding process can be more readily automated. This creates less need for more grinding machines, floor space, wheel changes, waste generation, and operators – which has many advantages when it comes to your time, cost, and safety measures.

4. Customizable

Vitrified CBN grinding wheels are engineered per specific customer applications so you can achieve optimal performance.

Considerations that can be taken into account include: material being ground, grinding machine, coolant type and delivery, dressing method, stock removal, quantity of parts, etc… And aggressive, free-cutting bonds can also adapt to various spindle speeds. Which is not only convenient, but also cost effective.

5. Lights Out Operation

Vitrified CBN grinding wheels have “dressable” structures – which lend them to “lights out operation.” The grinding layer can be refreshed using a rotary, and in some cases, stationary dresser.

You’ll be able to automate every step of the manufacturing process, making Vitrified CBN grinding wheels an excellent choice for production based applications.

6. Re-Truing of Formed Profiles

Another benefit of having a “dressable” structure is that complex forms and geometries are able to be generated in Vitrified CBN grinding wheels. The profiles are able to automatically regenerate in line on the properly equipped grinder and maintain tight tolerances.

7. environmentally friendly

The use of Vitrified CBN wheels (as opposed to conventional abrasive wheels) results in significant reductions in waste generation. It decreases the amount of grinding debris (swarf) >99%.

It even allows for more recycling of the metal swarf that is generated because it is oftentimes free of grinding wheel breakdown. Many customers are able to get credit for the Environmental and waste reduction initiatives under ISO14000 and other programs.

Experience the cost effective solution for production grinding with Vitrified CBN Grinding Wheels. Contact us for your free quote.

Why Different Materials Need Different Grinding Wheels

With all of the grinding wheel options available, figuring out which one is going to be the most efficient and cost effective for your working material can feel overwhelming, to say the least.

This article will help cover the basics as to why different materials will need different grinding wheels - and how to select the appropriate abrasive type for your grinding wheel.

So why exactly do different materials require different types of grinding wheels?

It comes down to the material properties (i.e. material hardness and chemistry) and the proposed grinding process: factors like machine, coolant, dressing, stock removal, etc.

First, consider which type of abrasive will be best for your material: conventional or superabrasive?

Conventional Abrasives

• Aluminum Oxide

• Silicon Carbide

Aluminum oxide has a hardness of 1800 HrV and is commonly used in grinding of ferrous or other materials that are known to chemically react with carbon.

Silicon carbide has a hardness of 2800 HrV and is used on "hard" materials such as glass, ceramics and non-ferrous metals such as aluminum and copper.

Superabrasives:

• Diamond

• Cubic Boron Nitride (CBN)

Superabrasives are both harder (longer lasting) and have much higher thermal conductivity (remove heat of grinding more efficiently) compared to conventional abrasives.

Diamond is the hardest known substance with a hardness of 9000 HrV and is the most effective abrasive in grinding of materials that don't react with carbon such as glass, ceramics, and non-ferrous metals. It can increase wheel life by several orders of magnitude when compared with conventional wheels. Advancements in production of synthetic or man-made diamonds have brought their cost down and led to expanded use. We commonly see diamonds used for grinding tough materials such as very hard steels, cemented carbide, and aluminum oxide cutting tools.

CBN is the second hardest known material at 4500 HrV and is ideal for grinding ferrous metals and other materials that are known to react with carbon. It is commonly utilized in the grinding of high-speed steel, hardened cast iron, tool and die steel, and stainless steels. When appropriately specified and optimized, CBN can outlast conventional Aluminum Oxide wheels by a factor of up to 300:1.

---

NOTE: With so many benefits, you may be wondering “What type of materials cannot be ground on a grinding wheel?” Superabrasives (Diamond & CBN) are focused on hard materials. We turn to CBN for hardened ferrous alloys, stainless steel, and nickel alloys. Diamond is ideal for even harder materials such as glass, carbides, and ceramics. The harder the material, the better it is for grinding with superabrasives, which is what we customize for our clients at Continental Diamond Tool.

You often cannot justify the cost of a superabrasive grinding wheel for soft nonferrous metals (<30 HrC) like aluminum, brass, and copper. Materials with such soft properties tend to “clog'' and coat the wheel and would require continuous dressing.

Some have asked, “Can you use a superabrasive grinding wheel on wood?" Wood is a very soft, inexpensive substance and would not be well suited for superabrasive grinding. For similar reasons, we do not recommend superabrasive grinding wheels for other soft nonmetallic materials like fabric, leather, certain plastics and rubber, etc.

---

Now that you know the differences between Conventional and Superabrasive grinding wheels, you can see how each caters better to different materials and uses. Once you’ve narrowed down the proper abrasive type, a grinding wheel expert can help you narrow your selection further with a selection of different bond types, such as Resin Bond, Metal Bond, Vitrified Bond, and Electroplated.

The bond is what holds the wheel’s abrasive grains together. The strength of bonding of a grinding wheel is often referred to as its hardness. Generally speaking, grinding wheels with a higher grade or hardness are recommended for softer materials and vice versa. It is also now possible to combine bonds to form custom hybrid variations that have unique properties.

---

NOTE: You may be thinking “Why do we use hard wheels for soft materials in grinding?” This is a complicated subject with the actual grinding mechanism (chip formation) being different between ductile or soft metals and hard materials like ceramics. Grinding wheels for metals act like micro-cutting tools where metal chips are cut or torn away. The chip size and shape is dependent on the material properties.

With harder materials such as carbides and ceramics, there are brittle fractures where small chips are actually fractured away in the grinding process. The material itself is very abrasive. Because the chips in carbide and ceramics are so abrasive, softer wheels are often more efficient at removing the small abrasive chips (a.k.a. swarf).

---

When shopping for a grinding wheel manufacturer, it’s helpful to have some basic parameters handy to get the most accurate quote and best product for your application. For a whole list of considerations to bring with you for selecting the best grinding wheel, check out our article on How To Order Custom Grinding Wheels.

Then contact us to collaborate with our engineers, product managers, and technical sales people to go over all of these considerations with you. If you’d like, we can even come to your facility to review your process first hand and make recommendations.

When you have the optimal grinding wheel for your material, you will see the difference in speed, durability, and performance.

Choosing the Right Grinding Wheel

Choosing the right grinding wheel for any given project is perhaps the MOST important part of the process… But why?

It’s because choosing the WRONG grinding wheel for your material can be catastrophic for a whole host of different reasons. It can lead to:

• Significant amounts of money lost

• Major time delays to complete your project

• Workpiece and/or machine damage resulting from running the wrong wheel or grinding process.

• Alterations to workpiece properties (i.e. changes in material hardness from grinding).

That’s why it’s so important to go over your options carefully, and discuss them with your technicians and engineers to ensure your grinding wheel is going to get you the most bang for your buck, the fastest completion time possible while still providing high quality results, and will be safe for all workers involved.

So what exactly is a grinding wheel used for?

You can think of grinding wheels as really really souped up sandpaper… Just like sandpaper helps smooth a surface or remove excess wood, a grinding wheel is an abrasive that’s used to:

• Remove any unnecessary material

• Create a specific shape

• Grind down your material

• Prepare metal for proper welding

However, unlike sandpaper, grinding wheels are effective on many materials in addition to wood. Grinding wheels are most frequently used for almost any type of metal material you’re working with – and they produce results at a MUCH faster rate than precision cutting, saving you time and money. They can even be effective at grinding plastics, glass, and non-metallic materials.

How do you choose what kind of grinding wheel to use?

You should consider what type of material you have that needs to be ground.

The grinding wheel you choose needs to be made of stronger material in order to have an impact. Different grinding wheel types will produce different results.

For example, if you were choosing a knife to cut a loaf of bread… A serrated knife will produce a cleaner cut than your butter knife.

Choose the material that will give you the cleanest, smoothest outcome.

Here are some other key things to discuss with your engineers to make sure you select the best kind of grinding wheel to use for your project:

• What material is being ground?

• What abrasive type should be used for that material?

• What size abrasive should be used (grain attribute)?

• How course, medium, or fine should the abrasive material be (grit size)?

• Coolant Type (if any)?

• And what bond type should be used?

Our team can help you review your equipment and processes, the parts you’re looking to grind, and provide recommendations (including whether or not a custom superabrasive grinding wheel is necessary for your unique project needs).

When should you invest in a custom superabrasive grinding wheel?

Custom superabrasive wheels are usually either made with diamond or from Cubic Boron Nitride (CBN).

If your material that needs grinding is made of iron or other alloys, then a superabrasive CBN grinding wheel is your best pick. If your material is made of carbon, choosing diamond can help sharpen. Or if you have material made of granite, choosing diamond can help create a glossier finish.

Essentially, superabrasives are made from some of the hardest materials mankind can make. Traditional abrasives (such as aluminum oxide or silicon carbide) are much softer materials that can break down much quicker.

And while traditional abrasives may be less expensive, if you’re in any of the following industries, using a superabrasive will bring you the best, safest results:

• Aerospace

• Automotive

• Medical

• Electronics

• Composites

• Oil Industry

CDT is proud to have a strong group of engineers, product managers, and technical sales people in our back pocket who are more than happy to go over all of these considerations with you. You can come to our offices, or we can come visit your facility.

Diamond Rotary Dressers by Type

Industry's increasing demand for high-accuracy, high-speed production has fostered a new branch of engineering technology to ensure grinding wheels are maintained in optimum condition. Diamond Rotary Dressers are now recognised as the most efficient and economic means of dressing and truing grinding wheels to the correct form, tolerance and condition. Their use is growing rapidly in the manufacture of components for automotive, aerospace, power generation, machine tool and precision engineering industries.

Leading in innovation

At Continental Diamond Tool Limited, we have been a frontrunner for decades in innovating rotary dresser technology. As far back as 1995, as Consort Precision Diamond Company, we won industry awards for our development of the high speed plating process which dramatically reduced previous lengthy plating times and is still in use today. We proudly holds the ISO 9001:2015 Registration Certificate for its Quality Management Systems, and we are continuously innovating to increase the efficiency and cost effectiveness of this industry-changing technology.

OUR FOUR MAIN PROCESSES

There are four distinct methods we use in the manufacture of our diamond rotary dressers: reverse plated, hand-set sintered, cvd sintered, and random set sintered. Each has its own benefits, as outlined below.

---

Type 1 - Reverse-Plated

The High Accuracy dresser

Reverse Plated Dressers are selected where high accuracy of profile detail is required together with a correspondingly high quality surface finish on the component.

Accuracy is achieved by centrifugal dispersion of the specially selected diamonds onto the walls of a mould. These are secured by our electro-deposition process that has won acclaim through the acquisition of industry awards, thereby achieving the short lead times so often required by customers.

The electro-deposition process is stable and unaffected by shrinkage, which results in Rotary Diamond Dressers of exceptional accuracy.

Tolerance Detail

General Surface Finish Produced: 0.4uM. 16 C.L.A.

Typical Applications

• Turbine Blade - Fir Tree Root Form

• Cam Grinding

• Bearing Industry

• Ball Joints

• Needle Injectors

---

Type 2 - Handset Sintered Dressers

A CONSORT PRECISION™ SPECIALTY

Of all the rotary dressers for which the Consort Precision name is known, Handset Sintered Dressers are our most popular type. These custom diamond rotary dressers cover many applications where robustness is required and the general tolerance is open.

As the name implies, diamonds are selected and set by hand in a mould, then secured in position by sintering in a tungsten based matrix. Allowances are made for consequential shrinkage to bring the finished dresser within specification tolerances.

Tolerance Detail

General Surface Finish Produced: 0.8uM. 32 C.L.A.

Typical Applications

• Turbine Blade

• Automobile Valves

• Crankshafts

---

type 3 - CVD Sintered

THE High Performance Dresser

Our CVD sintered rotary diamond dressers have very high thermal oxidation resistance and other excellent thermal properties. CVD is perfect for secure mounting with traditional non-ferrous metal sintering. CVD sintered rotary diamond dressers can also be brazed onto a dresser body using an active braze alloy in a non-oxidizing environment.

Benefits

• Highly resistant to chipping and fracture

• Wears evenly over the dresser's entire length

• Performs regardless of dressing orientation

• Outstanding thermal stability

CVD diamond can be manufactured in a multitude of shapes, sizes, thicknesses and grades giving engineers great flexibility with this material's extreme properties.

Dimensions

Our CVD diamond dressers can be ordered in all the standard rectangular dimensions in various lengths and square, but we also specialize in supplying non-standard custom dimensions upon request.

Typical Applications

• Metal matrix composites

• Aluminium alloys

• Glass-reinforced plastics

• Carbon fibre-based materials

• Plastics and rubbers

• Graphite

---

type 4 - random set sintered

The dresser FOR QUICK DELIVERY

Random Set Sintered Dressers are most suitable where openness is required, coupled with a tight form and improved surface finish.

Very often selected diamonds are strategically placed in the mould to support the form in vulnerable areas. The remaining area is then in-filled by centrifugal dispersion of diamonds and sintered.

Random Set Sintered Dressers have the advantage that they can be delivered quickly to meet urgent customer requirements.

Tolerance Detail

General Surface Finish Produced 0.4 uM. 16 C.L.A.

Typical Applications

• Automobile Valves

• Turbine Root Forms

• Flute Grinding

---

CHOOSING THE RIGHT DRESSER TYPE

Within each of these categories there are many further variables of appropriate diamonds and setting patterns to consider when ordering dressers of this type. Specialist techniques need specialist suppliers which is why we established our Consort Precision Diamond Rotary Dresser custom product line. Since 1984, we have dedicated substantial resources to developing the finest Diamond Rotary Dressers and support services available.

At Continental Diamond Tool Limited, we focus predominately on the design, development, manufacture, install and maintenance of Rotary Diamond Dressers. And we think that gives us a unique commitment to provide our customers with the best technology can offer.

If an application calls for a Diamond Rotary Dresser, Continental Diamond Tool will provide the best tool for the job. Contact us for a free consultation and quote.

How Does CDT Guarantee Grinding Wheel Performance?

Customer satisfaction is our first priority at Continental Diamond Tool, best illustrated by our Performance Payoff Guarantee. What is that? It's our pledge to customers to guarantee a return on their investment. To summarize, if we cannot match the quality or life of your current tooling, you won’t pay a penny more than what it's worth to you. Here’s how it works:

1. Continental Diamond Tool guarantees that all of our tooling will be manufactured to the requested abrasive and dimensional specifications.

At CDT your manufacturing team will work directly with our engineers to design, test, and build tools customized to your processes in your industry. CDT will calculate the ideal abrasive size and style to meet your requirements for stock removal and surface finish while also accounting for the type of material being ground. Combine this custom grit with the best type of bond and, voilá, we have a grinding wheel design that will yield optimal performance for your operation.

Then, using state-of-the-art equipment and stringent quality control standards, we move your order into prototype and/or production to achieve some of the tightest tolerances in the industry.

2. As the customer, you define the length of time, the application requirements, and the test’s measurement for success.

With our grinding lab, we can perform remote product testing to eliminate your risk before you even have your grinding wheel in hand. Direct benefits include:

·         Accelerated product development, with no conflict between product trials and actual production time.

·         More savings and less risk, with optimization taking place during simulations rather than costly trials.

·         Advanced innovation opportunities for exploring various product types and coolant delivery methods.

·         Superior, usable data, thanks to monitoring sensors that record every aspect of each grind.

Even with simulated trials in our grinding lab, we still welcome the opportunity to put our custom superabrasive grinding wheels to the test in your live production environment. Our engineers are happy to come to your facility to aid in the setup process, compile before-and-after data, and summarize the results.

3. If we cannot match your current tooling’s quality or life, we will only charge according to its value to you, based upon the current tooling’s cost.

We would never expect our customers to settle for average or subpar performance. We believe wholeheartedly in the abilities of our team to produce superior grinding solutions for our customers. Our confidence comes from our founding principles of service, quality, dependability, and precision. However, talk is cheap, and we are a company of action. The Performance Payoff Guarantee holds us accountable to our customers. With it, you can see exactly what you are getting with your investment.

Take, for example, the experience of Jim Elliott of Advanced Carbide. After investing in a new hybrid solution for their vitrified grinding wheel, and seeing the results of their performance payoff guarantee trial, here’s what Jim had to say: “With this new bond [from CDT], we saw cycle time reductions of 20% or more, and the same amount of wear compared to our first generation vitrified wheel, which was already a vast improvement over a conventional wheel.” Click here to read more about it.

With every specialty superabrasive grinding wheel we make, we strive to improve grinding time, reduce overall tooling cost, and hit ROI out of the park.

If you have product warranty questions — or would like to request a quote — please reach out to your CDT representative, call 800-443-6629, or contact us through our online form.

What Is a Diamond Rotary Dresser?

Grinding operations often work best with some form of wheel dressing to re-establish the wheel profile and/or recondition the wheel face. Wheel conditioning typically involves the sharpening and opening of the wheel face, while also removing dull abrasives, excessive bond, and workpiece material (loading). A sharp and open wheel face will allow maximum possible material-removal rates and reduced thermal stress on the workpiece. CDT engineers design each dresser to match your wheel topography so that it performs with superior strength and versatility. All are made with the highest quality CVD, natural diamond, synthetic diamond and combinations to maximize performance and roll life. Because they are custom manufactured, an abundance of configurations are possible.

Types of Diamond Rotary Dressers

There are two manufacturing methods for rotary dressers with several variations in setting/diamond application to best suit the customer application.  Below are several examples:

1. Reverse Plated Diamond Roll

Manufactured with high accuracy molds and a tightly controlled electroplating process to deposit the nickel layer.  The nickel layer holds the abrasive in place to allow for extremely complex profiles and tight tolerance work, which produce high quality surface finishes.  Because of the accuracy on the front end of the process, these rolls require little to no surface conditioning, which leave sharp natural points for superior dressing, resulting in an open grinding wheel and lower grinding forces.  Reverse plated rolls are ideal for continuous dress creep feed process, and complex forms like bearings, fuel injection, thread forms, and aerospace root forms.

2. Sintered Diamond Roll

Using a high temperature powdered metal process to create a tough tungsten matrix to secure the abrasive in the roll.  This product is ideal for aggressive grinding and harsh working environment, while still holding tight profile tolerances and complex forms.  These are all handset products, either pattern set or random set, to allow for a wide range of options on performance, surface finish, and roll life.  Because of the manufacturing process, these rolls generally have shorter lead times and can usually be reworked to meet production demands.  Sintered rolls are ideal for simple profile rolls to complex valve grinding assemblies.

3. Sintered CVD / Disc Dresser

These dressers use the same tough tungsten matrix as the standard Sintered rolls but are unique in the abrasive they are set with and how they are typically used.  They are available using synthetic, natural, or CVD abrasive and can be set in combination to target specific performance, surface finish, and roll life.  These are typically used to traverse across the grinding wheel to generate specific profiles and wheel conditions for open and free cutting grinding of the part.  This style dresser is ideal for reconditioning, which can restore the roll to its original profile and tolerance in half the normal lead time and a fraction of the cost.

Where Can You Get a Diamond Rotary Dresser?

If you're looking to purchase a diamond rotary dresser, then you should know that Continental Diamond Tool Corporation is the final place to get them.

Experience

Since 1973, our family-owned company has built a reputation as a leading-edge manufacturer with a commitment to excellence.

Quality

Our engineers are highly specialized, and all our products are produced under stringent quality control standards.

Customization

We manufacture to your specific needs, providing you with specialized tools in a timely manner, with guaranteed satisfaction.

Precision

Our state-of-the-art equipment and expertise give our products some of the tightest tolerances in the industry.

Personalized Tech Support

From prototype to production, operations, or replacement tooling, our team works closely to get you the solutions you need.

Multiple Ways to Request an Estimate

Submit your project specifications and upload large files through our website: www.cdtusa.net/contact

Email details of your project with small file attachments to: info@cdtusa.net

Call our customer service team to talk through your project and discuss options: 800.443.6629

Why Choose Continental Diamond Tool?

There are a lot of reasons to consider Continental Diamond Tool, but the top three reasons customers choose CDT are our high level of service, quality, and consistency.

Quality is the highest priority at CDT. We’re ISO Certified, with checks and balances in place to make sure each tool is the highest quality, every time.

Consistency means repeatability, so your tool is the same from one order to the next. You don’t deviate in your usage, so we have to nail it every time, with the tightest tolerances.

CDT has made customer service a main focus. Jeff Turner, Inside Sales, says, “It’s a priority that I take very seriously. Each customer should feel like they’re our biggest one.”

If you’re wondering why CDT, reach out to us. We will follow up so you can see if we can meet your needs, including our Grinding Lab, where we can show you first hand the benefits that you can get from our tooling.

Learn more about the reasons CDT is committed to you here:

What should you look for in a grinding wheel manufacturer?

When you’re in search of a supplier of custom manufactured grinding wheels, we know you’re going to be focused on three main components: delivery, performance, and support.

At CDT, we deliver engineered solutions to help you complete your project on time. We will also meet or exceed any requirements you have for surface finish, tolerance holding, cycle time reduction, or anything else for which you are needing engineer solutions. We also provide support throughout the duration of the entire project, from beginning to end.

“We provide information and support all along the way,” says Harrison Sheldon, Application Engineer.

Watch our video to find out more about our commitment to excellence for our customers:

Top 10 Super Characteristics of Superabrasives

Superabrasive grinding products get their ‘super’ characteristics from the extremely hard substances used to make them. Unlike conventional grinding wheels that are created using blends of less durable abrasive grains, superabrasives use industry’s the hardest known substances to achieve their abrasive properties.

Diamond has the most extreme Knoop hardness rating around 7,000, with synthetic or manmade diamonds having a more consistent hardness than its naturally occurring counterpart. The other popular superabrasive material, cubic boron nitride (CBN), is an extremely hard synthetic grain with a Knoop rating of 4,700. Conventional grains typically range from 2,100 to 2,500.

Upfront cost for these superabrasive grinding products is very high when compared to conventional abrasives, so what makes them so valuable to many industries? The secret is in this product’s return on investment.

Here are the top 10 reasons you should consider a superabrasive solution for your precision grinding or finishing process.

10. Decreased Cost Per Part

9. Decreased Cost in Swarf Management

8. Increased Production Parts Per Dress

7. Multiple Profile Grinds Without Dress

6. Less Residual Stress or Damage to the Part

5. Increased Throughput

4. Lower Grinding Pressure

3. Higher Removal Rates

2. Improved Surface Finish

…and the number one reason superabrasive products are a ‘super’ solution to your grinding and finishing needs:

1. Lower Overall Tooling Costs

When companies add up the superior precision, efficiency, quality, and durability that comes with a superabrasive grinding wheels, superabrasive grinding wheels and tools quickly justify their upfront cost.

If you are interested in a free quote, contact our customer service team to discuss how a superabrasive solution can be used to improve your company’s bottom line.

What is the benefit of having a grinding lab on site?

Here at CDT, we have a technologically advanced research and development grinding lab. This gives us the opportunity to work with customers to develop grinding processes that are specific to their materials, equipment, and applications. Our setup is unique, in that we’ve added numerous extra sensors to capture data on every element of the grinding process, to replicate what’s happening in the customer’s actual facilities.

We have a twofold product commitment to the Grinding Lab. One, we can develop processes for the customer and their specific application. Two, we can internally develop advanced new products that solve issues for customers before they are even known.

CDT’s customer service commitment includes the lab as well, inviting customers to reach out to us, to use our grinding lab to solve their grinding problems. Benefits to CDT customers include:

• Faster product development

• Cost savings/reduced risk

• Opportunities to innovate

• Valuable data

• Remote product testing

Read more about these benefits here or watch clips of the Grinding Lab in action, and hear more about it from Jeff Wirth, our Engineering Manager in this video:
